Quick Details

  • Machine Type: Abrator
  • Condition: New
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: HACHIEVE
  • Model Number: Q37XX
  • Feature: Non-Toxic, Rust / Corrosion Inhibitor
  • Fuel: Electric
  • Certification: CE
  • Use: Burnishing, Container / Bottle Cleaning
  • Cleaning Process: Steel shot ball
  • Cleaning Type: High speed sand blasting cleaning
  • Industry Used: Casing, Automobile, Machinery manufacturing
  • Material: Metal / Coil
  • Power(W): 20 kw
  • Dimension(L*W*H): Customized
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Hook Qty.: 1~16 pcs

Packaging & Delivery

Packaging Details export standard packing
Delivery Time 30 days

Specifications

1.Hook type sand / shot blasting machine
2.Compact structure
3.Blast 0.5T to 10T workpiece
4.Surface Descaling,rust cleaning

Hook Pass through Type Shot Blasting Machine for casting and welding workpiece



Product Description





Features:

  1. This Hanger Hook Type Shot Blasting Machine is a kind of high efficency shot blasting machine with non-pit.
  2. Large inner available cleaning space, compacted structure and scientific design. Can be designed and manufactured according to the order.
  3. No special request for the workpiece structure. Can be used for different kinds of workpieces.

    Widely used in cleaning and strengthening for Fragile or Irregularly Shaped Parts, Medium-sized or Large Parts, Die Cast Parts, Sand Removal and External Finishing.







Rotary hook type shot blasting machine Technical Parameter:

Item

Unit

Q376

Q378

Q379

Q3710

Q3720

Q3730

Q3750

Q3780

Diameter

mm

Ø600

Ø800

Ø800

Ø800

Ø1400

Ø1600

Ø1800

Ø2000

High

mm

1100

1500

1600

1850

2300

2200

2500

3000

Load capacity of single hook

kg

600

1000

1000

1000

2000

3000

5000

8000

Abrasive flow rate

kg/min

120*2

160*2

250*2

250*2

250*3

250*3

250*4

250*4

Cleaning times

min

16

14

14

14

14

14

Elevating amount

t/h

15

20

30

30

45

45

60

60

Separating amount

t/h

15

20

30

30

45

45

60

60

Ventilation capacity

m3/h

2800

8300

8300

9000

15000

15000

18000

18000

Power(no dust collector)

kw

22

30

37.4

36.55

61.27

64.4

78.4

81.5



Through-type shot blast cleaning machine technical parameters

Item

Unit

Q3720

Q3730

Q3750

Q3780

Workpiece Length

mm

Arbitrary

Arbitrary

Arbitrary

Arbitrary

Workpiece Width

mm

<5000

<5000

<5000

<5000

Workpiece Height

mm

<5000

<5000

<5000

3000

Load capacity of single hook

kg

2000

3000

5000

8000

Abrasive flow rate

kg/min

250*Blast wheel quantity

250*Blast wheel quantity

250*Blast wheel quantity

250*Blast wheel quantity

Cleaning speed

m

1~4

1~4

1~4

1~4

Elevating amount

t/h

Non-standard

Non-standard

Non-standard

Non-standard

Separating amount

t/h

Non-standard

Non-standard

Non-standard

Non-standard

Ventilation capacity

m3/h

Non-standard

Non-standard

Non-standard

Non-standard

Power(no dust collector)

kw

Non-standard

Non-standard

Non-standard

Non-standard





Other Roller through type shot blasting machine:



Parameter

Q698

Q6912

Q6915

Q6920

Q6925

Q6930

Q6940

The effective cleaning width(mm)

800

1200

1500

2000

2500

3000

4000

Dimesion of inlet opening

1600*800

1200*400

1700*400

2200*400

2700*800

3200*800

4200*400

The length of cleaning workpiece(mm)

1200-12000

1200-1600

1200-12000

1200-12000

3000-12000

2400-12000

4500-18000

The speed of conveyer(m/min)

0.5-4

0.5-4

0.5-4

0.5-4

0.5-4

0.5-4

0.5-4

The thickness of cleaning steel sheet (mm)

3-60

3-60

1.5-60

3-60

3-60

3-110

4.5-100

Shot ball flow rate (kg/min)

4*120

4*250

4*250

6*250

6*250

6*360

8*360

The shot ball first loading (kg)

4000

4000

4000

4500

4500

8000

11000

Roll brush adjusting height (mm)

200

200

350

450

600

850

900

Air capacity(m3/h)

22000

17560

19000

19550

27758

28050

38000

Total power (kw)

90

78.3

113.5

156.6

204.8

224.55

293.6









FAQ







If you are interested in this equipment, please don't hesitate to contact us!

If the machine is not suitable for your workpiece, please tell us the following infromation:



1)   What kind of workpiece will you clean?

2)   The size of workpieces(length, width and height of maximum  workpiece,Length, width and  height of minimum workpiece?)

3)   How many  the weight of maximum and minimum workpiece?

4)   Please tell us your requirement cleaning efficiency?



According to your infomation, the best machine will be designed for you



















We also can supply bigger hook type shot blasting machine or hook pass through type shot blasting machine attached below:













Company Information



 Some of our customer:







Ali certificate:




Our Services

1 The warranty period is 12 months

2 After-sales service

1)  Quality of products for one year to implement the "three guarantees." In the "Three Guarantees" period, that where a normal use of malfunction and damage (excluding wearing parts), the company is responsible for repair or replacement.

2)  In the warranty period, if quality problems arise, after receiving user notification within 24 hours by phone or fax (Tel: 0532-86168937) to give a reply.

3)   After warranty period, to provide quality services to users. We have enough easy-worn spare parts, ensure the quality and delivery time.



3 Guarantees

The company enforces “Brand” strategy; realize “Total Quality Control (TQC)” and ISO9001 International quality system certification.
