Quick Details

  • Machine Type: Abrator
  • Condition: New
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: HACHIEVE
  • Model Number: Qh698
  • Feature: Rust / Corrosion Inhibitor, Shot blasting cleaning
  • Fuel: Electric
  • Certification: CE, ISO
  • Use: Burnishing, Descaling / Stripping
  • Cleaning Process: steel shot,steel grit,steel cut wire shot
  • Cleaning Type: Automic
  • Industry Used: Casting industry / shipyard /building/steel construction/foundry
  • Material: Metal / Coil
  • Power(W): Customized
  • Dimension(L*W*H): Customized
  • After-sales Service Provided: Engineers available to service machinery overseas
  • PLC: SIEMENS
  • Workpiece width: 1-5m,according user's workpiece
  • Workpiece length: 1-12m,according user's workpiece
  • Workpiece height: 3-3000mm, according user's workpiece
  • Operate Type: Auto/ Manual
  • Power (V): 220/380/400/440V
  • HZ: 50/60Hz
  • Phase: 1/2/3 Ph
  • Blast wheel Qty.: 2~20
  • Blast wheel Power.: 7.5~75KW

Packaging & Delivery

Packaging Details: Our factory Seaworthy standard.
Delivery Detail: 30 Working days

Q698  H beam shot blasting machine /sand blasting equipment





Product Description



Usage:

 H beam shot blasting machine made in China, Cleaning Equipments in the processing refers to the former (that is, a state of raw materials) for shot blasting the surface rust and painted with a protective coat of processing technology. After pre-treatment of steel products can improve the mechanical and corrosion-resistant metal components ability of anti-fatigue properties of steel, extending its life; but also can optimize the production process of steel surface, and is conducive to cutting machine CNC cutting and precision blanking . In addition, pre-processing of steel as a result of comparing the shape of the rules in favor of mechanical and automated spray paint rust, so the use of steel pre-treatment can enhance the efficiency of clean-up, clean-up operations to reduce labor intensity and the pollution of the environment. In recent years, as a result of the use of PLC control, automation equipment, greater emphasis has been improved.





.Roller throuth type H beam and steel structure shot blasting machine Paramter:

Parameter

Q698

Q6912

Q6915

Q6920

Q6925

Q6930

Q6940

The effective cleaning width(mm)

800

1200

1500

2000

2500

3000

4000

Dimesion of inlet opening

1600*800

1200*400

1700*400

2200*400

2700*800

3200*800

4200*400

The length of cleaning workpiece(mm)

1200-12000

1200-1600

1200-12000

1200-12000

3000-12000

2400-12000

4500-18000

The speed of conveyer(m/min)

0.5-4

0.5-4

0.5-4

0.5-4

0.5-4

0.5-4

0.5-4

The thickness of cleaning steel sheet (mm)

3-60

3-60

1.5-60

3-60

3-60

3-110

4.5-100

Shot ball flow rate (kg/min)

4*120

4*250

4*250

6*250

6*250

6*360

8*360

The shot ball first loading (kg)

4000

4000

4000

4500

4500

8000

11000

Roll brush adjusting height (mm)

200

200

350

450

600

850

900

Air capacity(m3/h)

22000

17560

19000

19550

27758

28050

38000

Total power (kw)

90

78.3

113.5

156.6

204.8

224.55

293.6







2. Other Roller throuth type Cleaning Equipments Paramter:



NoNameUnitType1Type 2Type 3
1The width of the workpiecemmUnder 2500under3500Under 4500
2Model QXY2000, QXY2200, QXY2500QXY3000, QXY3200, QXY3500QXY3500, QXY4000, QXY4500
3Plate width (Max)mmThe number after  QXYThe number after  QXYThe number after  QXY
4Plate thickness 3~603~603~100
5The smallest section of profilemm*mm60*8060*80------
6The largest section of  profilemm*mm1000*3001000*300------
7The shortest workpiecemm240024002400
8Maximum workpiecemm120001200012000
9Conveyor speed m/s1~5(Note)0.5~4(Note)4~6(single)
10Derusting Quality Level ISO8501-1,1988GB8923-88(Bsa2.5)
11Surface roughness  μm40~7040~7040~70
12Paint Film thicknessμm15~2515~2515~25
13Paint type Quick-drying-type zinc-rich primerQuick-drying-type zinc-rich primerQuick-drying-type zinc-rich primer
14Installed PowerkwAccording to the actual situationAccording to the actual situationAccording to the actual situation
15Compressed air consumptionm3/min5~75~75~7
16Compressed air pressure rangeMPa0.4~0.60.4~0.60.4~0.6
17The first addition of the shot ballT8~108~1012~16





If the above model not suit for your workpiece, please tell me your need and the following information then we will send you the best technical drawing  to you.



1. The max. Length of the workpiece.
2. The max. Width of the workpiece.
3. The max. Height of the workpiece.
4. The productity you need to blasting the workpiece ( how many Tone per day or month?)
5. The power supply you need ( such as 380V, 3P, 50HZ)
6. Better to send us the workpiece photo or drawing.



1. H beam cleaning Equipment details photo:

















2. Steel plate shot blasting machine













Company Information

    Qingdao HACHIEVE. has been doing business more than 20 years. We have hundreds of shot blasting machines and component retrofits in operation in China and abroad serving every industry that utilizes blast cleaning technology.

Manufactured to meet your needs. Systems include:

• Structural Steel
          • Overhead Conveyor
          • Roller Conveyor
          • Work Car
• Steel Drum & Lid

• Plate Steel
• Plate Preservation Lines
• Bar & Wire/Coil Steel
• Wind Tower
• Rail Car

• Foundry
          • Table Blast
          • Tumble Blast
          • Spinner Hanger

Put our experience and expertise in the shot blast industry to work for you!
